Application:
Bearing tubular strander is mainly used for the twisting of copper, aluminum and ACSR, and bearing tubular strander is also suitable for the cabling of the small-section control cables.
Bearing tubular strander is mainly composed of fixed pay-off, 6-disc stranders, die holder, double wheel capstan, take-up & traverse rack, transmission system and electrical control system, etc. Bearing tubular strander can also add wrapping devices according to customer requirements.
Specification:
Type | JGGB-500 | JGGB-630 |
Single wire die (mm) | Copper: Φ1.0-Φ3.5 | Copper: Φ1.2-Φ3.5 |
Aluminum: Φ1.5-Φ5.0 | Aluminum: Φ1.5-Φ5.0 | |
Steel: Φ1.2-Φ3.5 | Steel: Φ1.2-Φ3.5 | |
Insulation wire core:Φ1.5-Φ5.0 m | Insulation wire core:Φ1.5-Φ7.0 m | |
Stranding die (MAX) (mm) | Φ15 | Φ15 |
Stranding pitch (mm) | 26-196 | 35-266 |
Taping pitch (mm) | 11-181 | 11-188 |
Capstan wheel (mm) | Φ1250 | Φ1250 |
Payoff bobbin | PND500 | PND630 |
Take-up bobbin | PN800-PN1600 | PN800-PN1600 |
Main motor (KW) | 30 (AC) | 45 (AC) |
|
